Air Cylinder – DNC SERIES Standard
Characteristics:
- This series of cylinder conforms to: ISO6431 standard.
- There is an adjustable buffers at the terminals of the cylinder except for mounted cushion.
- We can offer different kinds of mounting style according to ISO 6431 stardard, like Foot mounting, Front flange mounting, Rear-flange mounting,and so on.
- Different thread type can be offered according to customers’ requirements, e.g.:BSP, NPT etc.
- Needn’t lubricate on piston rod by oil
| BORE (mm) | STANDARD STROKE (mm) |
| 32 |
25, 40, 50, 80, 100, 125, 160, 200, 250, 320, 400, 500 |
| 40 | |
| 50 | |
| 63 | |
| 80 | |
| 100 | |
| 125 |
